Parameter |
Unit |
DTR-30 |
DTR-50 |
DTR-100 |
DTR-150 |
DTR-200 |
DTR-250 |
DTR-300 |
|
Flow rate |
L/h |
1800 |
3000 |
6000 |
9000 |
12000 |
15000 |
18000 |
|
Working vacuum |
MPa |
-0.08～-0.099 |
|||||||
Working pressure |
MPa |
≤0.3 |
|||||||
Temperature |
℃ |
20～80 |
|||||||
Power |
|
3 ph 380V 60Hz (Or as needed) |
|||||||
Working noise |
dB(A) |
75 |
75 |
75 |
75 |
80 |
80 |
80 |
|
Heating power |
kW |
30 |
30 |
45 |
60 |
75 |
90 |
120 |
|
Total power |
kW |
35.5 |
37.5 |
52.5 |
71.4 |
86.5 |
102.5 |
135 |
|
Oil Inlet/Outlet |
mm |
φ25 |
φ32 |
φ42 |
φ50 |
φ50 |
φ60 |
φ60 |
|
Weight |
Kg |
600 |
800 |
1050 |
1400 |
1800 |
2000 |
2200 |
|
Size |
Length |
mm |
1050 |
1100 |
1200 |
1450 |
1600 |
1800 |
1900 |
Width |
mm |
750 |
800 |
950 |
950 |
1100 |
1200 |
1200 |
|
Height |
mm |
1350 |
1400 |
1500 |
1650 |
1800 |
1900 |
1900 |
|
Index after clean |
BDV |
kV |
≥75 |
||||||
Moisture |
PPM |
≤3 |
|||||||
Gases |
% |
0.1 |
|||||||
Impurity |
μm |
≤5 or1 (customizable), no free carbon |
|||||||
IFT |
dynes/cm |
≥40 |
|||||||
Acid |
mgKOH/g |
≤0.03 |
|||||||
Dielectric loss factor |
Tgδ (90℃) |
≤0.001 |
|||||||
