1. Power supply：AC（220±10%）V, 50Hz;

2. Measurement distance：1.5m（±10mm）;

3. Heating mode：Electric heater;

4. Heating power：4500W;

5. Temperature control mode：Shield type cold heat balance pressurization cycle system;

6. Temperature control range：(5~50)℃, adjustable. Resolution is 0.01℃;

7. Temperature control accuracy：±0.1℃;

8. Tensile speed：10mm/min and 50mm/min, two grades;

9. Measurement accuracy：±1 mm;

10. Ductility display：Display in real time;

11. Ductility record：By touching screen

12. Average ductility：When the ductility record is finished, automatically display in the screen;

13. Refrigeration mode：Compressor refrigeration;

14. Ambient temperature： (15~+35)℃; Relative humidity：  ≤85%;

Total power consumption： ≤5600W;

Dimension: 2370×520×1000mm; Net wet: 285kg.
