No |
Item |
Specifications |
1 |
Test force |
|
1.1 |
Axial test force working range |
10~10000N |
1.2 |
Relative error of test force indication |
±1% |
1.3 |
Test force long time automatic maintaining indication error |
±1%F.S |
2 |
Friction torque |
|
2.1 |
Friction torque measuring range |
0~13500N.mm |
2.2 |
Relative error of friction torque indication |
±3% |
3 |
Spindle speed |
|
3.1 |
Spindle frequency conversion speed regulation range |
10~2000r/min |
3.2 |
Spindle speed error |
±5r/min |
4 |
Oil tank stroke |
>45mm |
5 |
Spindle bore taper |
1:7 |
6 |
Testing machine heating system |
|
6.1 |
Heater operating temperature range |
Room temperature~250℃ |
6.2 |
Temperature control accuracy |
≤2℃ |
7 |
Testing Machine Spindle Control |
|
7.1 |
Testing machine time display & control range |
1~99999s or 1-99999min |
7.2 |
Testing machine revolution display & control range |
999999999 |
7.3 |
Max torque output of testing machine main motor |
2.3N.m |
8 |
Oil quantity used in one test |
Around 10ml |
9 |
Special standard steel ball diameter |
Ф12.7 |
10 |
Rated power |
5.5KW |
11 |
Dimensions |
Around 116×75×164cm |
12 |
Net weight |
Around 400kg |
